The distance between x_1$\displaystyle x_{1}$ and x_2$\displaystyle x_{2}$ is computed by line-length​(​x1, x2​). The distance between y_1$\displaystyle y_{1}$ and y_2$\displaystyle y_{2}$ is computed by line-length​(​y1, y2​). Below is the equation to compute the hypotenuse of a right triangle with those amount for legs:

√( line\mbox-length(x_2, x_1)^2 + line\mbox-length(y_2, y_1)^2 )$\displaystyle \sqrt{line\mbox{-}length(x_{2}, x_{1})^2 + line\mbox{-}length(y_{2}, y_{1})^2}$

Suppose your player is at (0, 2) and a character is at (4, 5). What is the distance between them?

1. Identify the values of x_1$\displaystyle x_{1}$, y_1$\displaystyle y_{1}$, x_2$\displaystyle x_{2}$, and y_2$\displaystyle y_{2}$

x_1$\displaystyle x_{1}$ y_1$\displaystyle y_{1}$ x_2$\displaystyle x_{2}$ y_2$\displaystyle y_{2}$

(x-value of 1st point)

(y-value of 1st point)

(x-value of 2nd point)

(y-value of 2nd point)

The equation to compute the distance between these points is:

√( line\mbox-length(4, 0)^2 + line\mbox-length(5, 2)^2 )$\displaystyle \sqrt{line\mbox{-}length(4, 0)^2 + line\mbox{-}length(5, 2)^2}$

2. Translate the expression above, for (0,2) and (4,5) into a Circle of Evaluation below.

Hint: In our programming language num-sqr is used for x^2$\displaystyle x^2$ and num-sqrt is used for √x$\displaystyle \sqrt{x}$

3. Convert the Circle of Evaluation to Code below.
