The distance between x_1 and x_2 is computed by linelength(x1, x2)
. The distance between y_1 and y_2 is computed by linelength(y1, y2)
. Below is the equation to compute the hypotenuse of a right triangle with those amount for legs:
√( line\mboxlength(x_2, x_1)^2 + line\mboxlength(y_2, y_1)^2 )
Suppose your player is at (0, 2) and a character is at (4, 5). What is the distance between them?
1. Identify the values of x_1, y_1, x_2, and y_2
x_1  y_1  x_2  y_2

(xvalue of 1st point)
(yvalue of 1st point)
(xvalue of 2nd point)
(yvalue of 2nd point)

The equation to compute the distance between these points is:
√( line\mboxlength(4, 0)^2 + line\mboxlength(5, 2)^2 )
2. Translate the expression above, for (0,2) and (4,5) into a Circle of Evaluation below.
Hint: In our programming language numsqr
is used for x^2 and numsqrt
is used for √x
3. Convert the Circle of Evaluation to Code below.
